2-Port CAN-Bus PCI Express Card

Introduction

The PCIe-2CAN 2-Port CAN-Bus PCI Express Card is a plug-and-play, high-speed serial I/O expansion card designed for the PCI Express bus. By connecting to the PCI Express bus on your computer, this card instantly adds two CAN Bus communication ports to your system. It is engineered with the Exar XR17V352 PCI Express to UART chip and incorporates an ARM Cortex-M0 32-bit microcontroller for optimal performance.

Features

• PCI Express 2.0 Gen 1 compliant
• PCI Express 1 Lane compliant
• CAN bus speed up to 1Mbps
• One DB25 female to two DB9 male adapter cable for CAN Bus communication
• Installs as a standard Windows COM port
• Supported CAN modes: Standard, Listen, Echo
• Can be controlled over serial port using ASCII commands
• Easy to use API provided along with sample source codes and GUI sample programs
• Supports CAN 2.0A and CAN 2.0B protocols
• Drivers provided for Windows and Linux OS
• Wide ambient temperature operation 0°C to 60°C (32°F to 140°F)

Package Contents

• 2-Port CAN-Bus PCI Express Card
• DB25 Female to Dual DB9 Male Adapter Cable

Product Specifications
